OM SYSTEM OM-1 Mark II User Manual

Operating environment
Temperature
−10°C – 40°C (14 °F – 104°F) (operation)/ −20°C – 60°C (−4°F –
140°F) (storage)
Humidity 30% – 90% (operation)/ 10% – 90% (storage)
Water resistance
IEC Standard publication 60529 IPX3 (applies if camera is used with
our IPX3 or higher water-resistant lens)
Lithium-ion battery
MODEL NO. BLX-1
Type Rechargeable Lithium-ion battery
Nominal voltage DC7.2V
Nominal capacity 2280mAh
No. of charge and discharge times Approx. 500times (varies with usage conditions)
Ambient temperature 0°C – 40°C (32°F – 104°F) (charging)
Dimensions
Approx. 40mm (W) × 22mm (H) × 55mm (D) (1.6” × 0.9” ×
2.2”)
Weight Approx. 86g (3.1oz.)
USB-AC adapter
MODEL NO. F-7AC-1/F-7AC-2
Rated input AC 100V – 240V (50/60Hz)
Rated output DC 5V, 3A DC 9V, 3A
Ambient temperature
0°C – 40°C (32°F – 104°F) (operation)/ −20°C – 60°C (−4°F – 140°F)
(storage)
508
Specifications

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
