The selected GND number, filter type, and T indicating the
side to which the effect is applied appearin the display.
The black side of the T icon is the side to which the effect
is applied (the dimmed side).
100
%
100
%
GND8
-
S
ResetReset
1
Boundary
1
Shooting
Press the MENU button to close the Live GND Shooting setting screen and return to shooting
screen.
Adjust the angle and position of the boundary while previewing the results in the display.
Adjust the boundary angle using the front and rear dials. The front dial adjusts the angle in
increments of 15°, the rear dial in increments of 1°.
Adjust the boundary position using the arrow pad.
To reset the angle and position of the boundary, press and hold the OK button.
The slowest shutter speed available varies with the GND filter selected.
[GND2(1EV)]: 1/16000 s
[GND4(2EV)]: 1/8000 s
[GND8(3EV)]: 1/4000 s
[Image Aspect] (P.218) and [Digital Tele-converter] (P.259) settings are not applied to the
live view in the screen for adjusting the boundary(However, they are applied to the saved
image).
When an option other than [4:3] is selected for [Image Aspect]or [On] is selected for
[Digital Tele-converter], a frame will appear on the screen to indicate the area that will be
shown in the shot image.
To adjust aperture, shutter speed, and other shooting settings, press the INFO button.
The camera will return to the standard shooting display.
To return to the live GND shooting settings shown in Step 1, press the INFO button
repeatedly.
248
Shooting scenes with high contrast (Live GND
Shooting)
1.
2.
C
C
3.
