OM SYSTEM OM-1 Mark II User Manual

External Monitor Display Options (HDMI
Settings)
P A S M B n
Choose the signal output to external monitors connected via HDMI. Adjust the frame rate, movie frame
size, and other settings according to monitor specifications.
Menu
MENU U e U 3. Monitor/Sound/Connection U HDMI Settings
Output Size
Choose the type of signal output to the HDMI connector.
[C4K]: The signal is output in 4K digital cinema (4096 × 2160) format.
[4K]: If possible, the signal is output in 4K (3840 × 2160).
[1080p]: If possible, the signal is output in Full HD (1080p).
[720p]: If possible, the signal is output in HD (720p).
Output
Frame Rate
Choose the signal frame rate according to whether the device supports NTSC or PAL.
[60p Priority]: Frame rate for areas supporting NTSC.
[50P Priority]: Frame rate for areas supporting PAL.
[Output Frame Rate] cannot be changed when the camera is connected to a device via HDMI.
Sound will not be played back unless the connected device is compatible with the sound format.
You can configure detailed options for when outputting signals to an HDMI device in movie mode.
g“HDMI Output (nHDMI Output)” (P.285)
404
External Monitor Display Options (HDMI
Settings)
C
C
B

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
