OM SYSTEM OM-1 Mark II User Manual

Touch AF Target Selection for Viewfinder
Photography (AF Targeting Pad)
P A S M B n
Use touch controls in the monitor to select the AF target during viewfinder photography. Glide a finger
over the monitor to position the focus target while viewing your subject in the viewfinder.
Menu
MENU U AF U 6. AF Target Settings & Operations U AF Targeting Pad
Off
Monitor touch controls cannot be used for AF target selection during viewfinder
photography.
On
Monitor touch controls can be used for AF target selection during viewfinder photography.
Gently tap the monitor twice to enable or disable touch AF target selection. When the target
reaches the edge of the display and you lift and glide your finger again, the AF target
moves to the other side or becomes bAll (all target) mode depending on the [Y Loop
Selection] (P.141) setting.
When [On] is selected, touch controls can also be used to position the zoom frame (P.111).
143
Touch AF Target Selection for Viewfinder
Photography (AF Targeting Pad)
B

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
