Highlight a RAW image to overlay using the FGHI
buttons and press the OK button.
The P icon will appear on the selected image. To remove
the P icon, press the OK button again.
The overlaid image will be displayed if images of the
number specified in Step 3 are selected.
RAW
RAW RAW
RAW
RAW RAW RAW
Image Overlay
MENU
OK
1
Adjust the gain for each of the images in the overlay.
Highlight images using the HI buttons and adjust gain
using the FG buttons.
Gain can be adjusted in the range 0.1 – 2.0. Check the results
in the monitor.
MENU
OK
1
x1.0 x1.0 x1.0
Image Overlay
Combining Pictures (Image Overlay)
Overlay existing RAW photos and to create a new picture. Up to 3 pictures can be included in the
overlay.
The results can be modified by adjusting brightness (gain) separately for each picture.
The overlay is saved in the format currently selected for image quality. Overlays created with [RAW]
selected for image quality are saved in RAW format and in JPEG format using the image quality
option selected for [X2] (P.211).
Overlays saved in RAW format can in turn be combined with other RAW images to create overlays
containing 4 or more pictures.
Display an image you want to edit and press the OK button.
The playback direct menu will be displayed.
Highlight [Image Overlay] using FG and press the OK button.
Select the number of images to be overlaid and press the OK button.
Press the OK button; a confirmation dialog will be displayed.
Highlight [Yes] and press the OK button.
324
Combining Pictures (Image Overlay)
B
B
1.
2.
3.
4.
5.
6.

Table of Contents

Other manuals for OM SYSTEM OM-1 Mark II

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the OM SYSTEM OM-1 Mark II and is the answer not in the manual?

OM SYSTEM OM-1 Mark II Specifications

General IconGeneral
Camera TypeMirrorless
Sensor Resolution20.4MP
Image ProcessorTruePic X
ConnectivityWi-Fi, Bluetooth, USB-C, HDMI
Body ConstructionMagnesium Alloy
Dimensions134.8 x 91.6 x 72.7 mm
Sensor SizeFour Thirds
ISO RangeISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization5-axis in-body
Autofocus System1053-Point Hybrid Autofocus
Viewfinder TypeElectronic (EVF)
Viewfinder Resolution5.76 million dots
Viewfinder Magnification1.65x (35mm equivalent)
Rear Screen3.0" vari-angle touchscreen
Rear Screen Resolution1.62 million dots
Video Recording4K UHD at 60p/50p/30p/25p/24p
Video FormatMOV
Audio RecordingStereo, external mic input
Storage MediaDual SD Card Slots (UHS-II)
BatteryBLX-1 Lithium-Ion Battery
Weight599 g (with battery and memory card)
Battery LifeApprox. 520 shots (CIPA standard)
Shutter Speed1/8000 to 60 sec
Weather SealingYes (IP53 rated)
