Keeping the shutter button pressed halfway, rotate the focus ring to adjust focus manually.
To refocus using autofocus, release the shutter button and press it halfway again.
Manual focus adjustment during autofocus is not available in [RAFJ] mode.
Manual focus adjustment during autofocus is available via the focus ring on M.ZUIKO PRO
(Micro Four Thirds PRO) lenses. For information on other lenses, visit our website.
Press the shutter button the rest of the way down to take the picture.
104
Choosing a focus mode (KAF Mode / nAF
Mode)
3.
C
B
4.

Table of Contents

Other manuals for OM SYSTEM OM-1 Mark II

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the OM SYSTEM OM-1 Mark II and is the answer not in the manual?

OM SYSTEM OM-1 Mark II Specifications

General IconGeneral
Camera TypeMirrorless
Sensor Resolution20.4MP
Image ProcessorTruePic X
ConnectivityWi-Fi, Bluetooth, USB-C, HDMI
Body ConstructionMagnesium Alloy
Dimensions134.8 x 91.6 x 72.7 mm
Sensor SizeFour Thirds
ISO RangeISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization5-axis in-body
Autofocus System1053-Point Hybrid Autofocus
Viewfinder TypeElectronic (EVF)
Viewfinder Resolution5.76 million dots
Viewfinder Magnification1.65x (35mm equivalent)
Rear Screen3.0" vari-angle touchscreen
Rear Screen Resolution1.62 million dots
Video Recording4K UHD at 60p/50p/30p/25p/24p
Video FormatMOV
Audio RecordingStereo, external mic input
Storage MediaDual SD Card Slots (UHS-II)
BatteryBLX-1 Lithium-Ion Battery
Weight599 g (with battery and memory card)
Battery LifeApprox. 520 shots (CIPA standard)
Shutter Speed1/8000 to 60 sec
Weather SealingYes (IP53 rated)
