OM SYSTEM OM-1 Mark II User Manual

When the shutter button is pressed halfway, a capture icon
(D) will be displayed. If the button is kept pressed halfway
for over a minute, capture will end and the D icon will clear
from the display. Press the shutter button halfway again to
resume shooting.
Shooting will continue while the shutter button is pressed
all the way down, up to the number of shots selected for
[Frame Count Limiter].
1
10231023
P
1 / 250
P
1 / F 250 5.65.6
1
1
[
1
:
02
:
03
][
1
:
02
:
03
]
FF 60p60p L
-
8L
-
8
S
-
AFS
-
AF
33
L
1
4K
ISO
Auto
ISO
Auto
F
00
+
-
0.00.0
100 % 100 %
200200
Pro Capture SH2 (ProCap SH2)
The camera shoots at up to 50 fps. A maximum of 99 frames can be captured before the shutter button
is pressed all the way down. If [C-AF], [C-AFJ], [C-AF+TR], or [C-AF+TRJ] is selected for [KAF
Mode] (P.100), the camera will focus before each shot.
The [ProCap SH2] mode is only available with specific lenses. Visit our website for details.
Using [C-AF], [C-AFJ], [C-AF+TR] or [C-AF+TRJ] AF mode (P.100) and an aperture value
larger than F8 in [ProCap SH2] mode, the focus accuracy will decrease. NF will be displayed on the
screen.
In [ProCap SH2] mode, the lower limit of the shutter speed is 1/640 s when [Max fps] under
[Sequential Shooting Settings] is set to [50fps] and 1/160 s when it is set to [25fps], [16.7fps], or
[12.5fps].
Button
gYA Button UHIi
Super control panel
OK U Drive (g/Y)
Menu
MENU U a U 7. Drive Mode U Drive g/Y
Select ProCap, ProCap SH1, or ProCap SH2 and press the OK button.
Press the shutter button halfway to start capturing.
[Max fps], [Pre-shutter Frames], and [Frame Count Limiter] can be adjusted in
[Sequential Shooting Settings] (P.193).
Press the shutter button all the way down to start saving pictures to the memory card.
201
Shooting without a release time lag (Pro Capture
shooting)
C
C
C
1.
2.
B
3.

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
