OM SYSTEM OM-1 Mark II User Manual

Role Function
Shooting mode
P A S M B
ISO Adjust ISO sensitivity.
P P P P P
WB (WB) Adjust white balance.
P P P P P
CWB Kelvin (CWB Kelvin)
Adjust the color temperature when
CWB (Custom WB) is selected for white
balance.
P P P P P
Off None.
P P P P P
Switch between Bulb, Time, and Live Comp.
The functions that can be assigned in [nDial Function] are listed below.
Role Function
nMode
(Movie exposure mode)
P A S M
Shutter Speed (Shutter) Choose the shutter speed. — —
P P
Aperture Value (FNo.) Adjust aperture. —
P
—
P
Exposure Comp. (F)
Adjust exposure compensation.
P P P P
ISO Adjust ISO sensitivity. — — —
P
WB (WB) Adjust white balance.
P P P P
CWB Kelvin (CWB Kelvin)
Adjust the color temperature when
CWB (Custom WB) is selected for white
balance.
P P P P
Sound Recording Level
(cVol)
Adjust the recording volume.
P P P P
Headphone Volume (9Vol)
Adjust the headphone volume.
P P P P
348
Assigning Roles to the Front and Rear Dials
(KDial Function / nDial Function)
1

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
