OM SYSTEM OM-1 Mark II User Manual

Highlight [0RAW/Control] using the FG buttons and
press the OK button.
USB
MTP
Webcam
0
RAW/Control
USB PD
Exit
OK
Storage
When prompted to choose the connection type, click [USB
Connection].
1
[USB Connection]
1
Launch the copy of “OM Capture” installed on the computer.
Configure OM Capture for download.
Choose a destination for the downloaded pictures.
Take pictures using camera or computer controls.
The pictures will be downloaded to the computer according to the options chosen.
See online help for more information on using the software.
The computer cannot be used to change the camera shooting mode.
The camera display frame rate may drop if the view through the camera lens is displayed
simultaneously both on the computer and in the camera monitor.
The connection to the computer will end if you:
exit “OM Capture”,
insert or remove memory cards, or
turn the camera off.
463
Uploading Pictures as They Are Taken
(0RAW/Control)
3.
4.
5.
6.
C
C
C
-
-
-

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
