Bit Switches – 4
D0C5/D0C6/D0C4/D0AP FAX UNIT 84 SM
1 1 1 0 33.6
Other settings - Not used
4-5 Initial modem type for 9.6 k or
7.2 kbps.
These bits set the initial modem type for 9.6 and 7.2
kbps if the initial modem rate is set at these speeds.
Bit 5 Bit
4
Setting
0 0 V.29
0 1 V.17
1 0 V.34
1 1 Not used
6-7 Not used Do not change the settings.
G3 Switch 06 (SP No. 1-105-007)
No Function Comments
0-3 Initial Rx modem rate(kbps) These bits set the initial starting modem rate for
the reception.
Use a lower setting if high speeds pose
problems during the reception.
If a modem rate 14.4 kbps or slower is
selected, V.8 protocol should be disabled
manually.
Cross-reference
V.8 protocol on/off - G3 switch 03, bit2
Bit 3 Bit
2
Bit
1
Bit
0
kbps
0 0 0 1 2.4
0 0 1 0 4.8
0 0 1 1 7.2
0 1 0 0 9.6
0 1 0 1 12.0
0 1 1 0 14.4
0 1 1 1 16.8
1 0 0 0 19.2
1 0 0 1 21.6
1 0 1 0 24.0
1 0 1 1 26.4
1 1 0 0 28.8
1 1 0 1 31.2
1 1 1 0 33.6
Other settings - Not used
4-7 Modem types available for reception
The setting of these bits is used to inform the transmitting terminal of the available modem
type for the machine in receive mode.
If V.34 is not selected, V.8 protocol must be disabled manually.
Cross-reference
V.8 protocol on/off - G3 switch 03, bit 2
