Ricoh SAVIN D0AP - Sp7-XXX (Tests)

Service Tables
D0C5/D0C6/D0C4/D0AP FAX UNIT 50 SM
feature.
106 Journal Print out
001 All Journals The machine prints all the communication records on the
report.
002 Specified Date The machine prints all communication records after the
specified date.
107 Log List Print out
001 All log files These log print out functions are for designer use only.
002 Printer
003 SC/TRAP Stored
004 Decompression
005 Scanner
006 JOB/SAF
007 Reconstruction
008 JBIG
009 Fax Driver
010 G3CCU
011 Fax Job
012 CCU
013 Scanner Condition
108 IP Protocol Dump List
001 All Communications Prints the protocol dump list of all communications for the IP
fax line.
002 1 Communication Prints the protocol dump list of the last communication for the
IP fax line.
4.2.7 SP7-XXX (TESTS)
These are the test modes for PTT approval.
7 Function
101 G3-1 Modem Tests
102 G3-1 DTMF Tests
103 Ringer Test
104 G3-1 V34 (S2400baud)
105 G3-1 V34 (S2800baud)
106 G3-1 V34 (S3000baud)
107 G3-1 V34 (S3200baud)
108 G3-1 V34 (S3429baud)
109 Recorded Message Tes t
