Paper Transfer Quality Standards
D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1 3-4 SM
3.3 PAPER TRANSFER QUALITY STANDARDS
Engines
Item Specification Remarks
Margin
position
Single Side:
Main Scan: 0 ± 2.5 mm
Sub Scan: 0 ± 2.0 mm
Duplex:
Main Scan: 0 ± 2.5 mm
Sub Scan: 0 ± 2.0 mm
Skew Single Side:
± 1.8 mm/200 mm or less (B5 SEF
or more)
± 1.3 mm/100 mm or less (Less
than B5 SEF)
Duplex:
± 1.3 mm/100 mm or less (B5 SEF
or more)
± 1.8 mm/100 mm or less (Less
than B5 SEF)
Not applicable to paper fed from the bypass
tray (Reference value when using the bypass
tray: ± 1.0 mm/100 mm)
Curling
after fusing
20 mm or less from the leading and
trailing edges with a radius of 40
mm or greater.
In an office environment
SPDF
Item Specification Remarks
Margin
position
Main Scan: 0 ± 1.5 mm
Sub Scan: 0 ± 2.0 mm
Skew Single Side/ Duplex
± 2.0 mm/200 mm or less (B5 SEF or more)
± 2.5 mm/200 mm or less (Less than B5 S EF, excluding A6 SEF and
B6 SEF)
± 3.7 mm/200 mm or less (A6 SEF, B6 SEF)
These standards are determined using standard paper under standard conditions.
Values may vary depending on environmental conditions such as temperature, humidity, use of
used paper, etc.
