Ricoh SAVIN D0AP - Registration Roller

Paper Feed
D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1 4-116 SM
4.15.11 REGISTRATION ROLLER
1. Remove the bypass feed unit. (Bypass Feed Unit)
2. Remove the HVPS with the bracket. (HVPS with the Bracket)
3. Remove the bearing [A] of the registration drive roller on the left side.
4. Remove the registration clutch (CL5). (Registration Clutch (CL5))
5. Remove the bearing [A] of the registration drive roller on the right side.
6. Remove the registration sensor (S5). (Registration Sensor (S5))
