USB Device Server Option Type M19A (D3BC-33, -34)
D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1 2-92 SM
2.18 USB DEVICE SERVER OPTION TYPE M19A (D3BC-33,
-34)
2.18.1 ACCESSORIES
No. Description Q’ty
1 USB cable 1
2 Interface board 1
3 Ferrite core 2
4 Cable ties 2
Ethernet cable is not provided with this option.
Interface Board Surface
No. Item Description
1 Switch Use to reset to the factory settings.
2 Ethernet port Use to connect the Ethernet cable.
3 USB port Use to connect this option to the main machine.
