Ricoh SAVIN D0AP - NVRAM on the BCU

Electrical Components
SM 4-155 D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1
Replacement
&
Adjustments
8. Turn the main power ON and enter the SP mode.
9. Enter the BCU serial number with SP5-811-004.
If the BCU serial number is not entered correctly, SC995-01 (serial number entry error) will
occur.
10. Power cycle the machine.
NVRAM on the BCU
1. Print out the SMC Report (factory settings) with SP5-990-006.
2. Print out the SMC Report (all data) with SP5-990-001.
3. Turn the main power OFF.
4. Install an SD card into SD Card Slot 2 (lower slot).
5. Turn the main power ON.
6. Copy the NVRAM data to an SD card with SP5-824-001.
7. Turn the main power O F F. Disconnect the power cord.
8. Replace the NVRAM on the BCU and reassemble the machine. (BCU (Printer Model))
9. Connect the power cord. Then turn the main power ON.
When you do this, SC995 will be displayed. However, DO NOT turn the main power OFF.
Continue with this procedure.
10. Select the destination setting with SP5-131-001. (JPN: 0, NA: 1, EU/AA/TWN/CHN: 2)
11. Enter the BCU serial number and area code.
• For information on how to configure this S P, contact the supervisor in your branch
office.
• Refer to the following area code/destination list.
1: Japan
2: North America
3: Europe
4: Ta i w a n
5: Asia
6: China
7: Korea
12. Power cycle the machine.
If the BCU serial number is not entered correctly, SC995-01 (serial number entry error) will
occur.
13. Copy the data from the SD card to the new NVRAM with SP5-825-001.
14. Turn the main power OF F.
