4.5 BIT SWITCHES – 3
• Do not adjust a bit switch or use a setting that is described as "Not used", as this may
cause the machine to malfunction or to operate in a manner that is not accepted by
local regulations. Such bits are for use only in other areas, such as Japan.
Default settings for bit switches are not listed in this manual. Refer to the System Parameter List
printed by the machine.
4.5.1 COMMUNICATION SWITCHES
Communication Switch 00 (SP No. 1-104-001)
No Function Comments
0-1 Compression modes available in
receive mode
These bits determine the compression capabilities to be
declared in phase B (handshaking) of the T.3 0 protocol.
Bit
1
Bit
0
Modes
0 0 MH only
0 1 MH/MR
1 0 MH/MR/MMR
1 1 MH/MR/MMR/JBIG
2-3 Compression modes available in
transmit mode
These bits determine the compression capabilities to be
used in the transmission and to be declared in phase B
(handshaking) of the T.30 protocol.
Bit
3
Bit
2
Modes
0 0 MH only
0 1 MH/MR
1 0 MH/MR/MMR
1 1 MH/MR/MMR/JBIG
4 Not used Do not change the settings.
5 JBIG compression method:
Reception
0: Only basic supported
1: Basic and optional both
supported
Change the setting when communication problems
occur using JBIG compression.
6 JBIG compression method:
Transmission
0: Basic mode priority
1: Optional mode priority
Change the setting when communication problems
occur using JBIG compression.
