Input and Output Check
D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1 3-4 SM
SP No. SP Name Value Comments
0 1
5-803-023 Key Counter Set2 Not set Set
5-803-024 Key Counter Set1 Set Not set
5-803-025 Key Card Set Set Not set
5-803-026 Rear Cover Open Cover open Cover close
5-803-027 Paper Nearend Paper present No paper
5-803-083 Bank1:500/250/No - - 0: 500
1: 250
2: None
5-803-084 Bank2:500/250/No - -
5-803-085 Bank3:500/250/No - -
5-803-087 Bank1 Trans SN No paper Paper present
5-803-088 Bank2 Trans SN No paper Paper present
5-803-089 Bank3 Trans SN No paper Paper present
5-803-200 Scanner HP Sensor Out of HP At HP
5-803-201 Platen Cover Sensor Closed Open
6-011-009 Original Detection Original not set Original set
6-011-010 Feed After sensor No paper Paper present
6-011-013 Registration Sensor No paper Paper present
6-011-015 Feed Cover Sensor Cover closed Cover open
6-011-024 Page Keeper Sensor No double-feed Double-feed
detected
3.2.2 OUTPUT CHECK
SP No. SP name Operation Restriction
5-804-001 FusPressRelMt:CW Rotates fusing
pressure/release motor
forward.
Cannot switch on with
fusing unit set.
5-804-002 FusPressRelMt:CCW Rotates fusing
pressure/release motor in
reverse.
5-804-003 DrumMt:CW:ExHi Rotates drum motor forward. Cannot switch on with
PCDU set.
5-804-004 DrumMt:CW:Hi
5-804-005 DrumMt:CW:Mid
5-804-006 DrumMt:CW:Low
5-804-007 DrumMt:CW:ExLow
5-804-008 DrumMt:CCW:ExHi Rotates drum motor in reverse.
