Data Overwrite Security Unit Type M19 (D3BS-03)
SM 2-123 D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1
2.27.5 INSTALLATION PROCEDURE
To prevent injury from electrical shock or damage to the machine, before installation always,
turn the main machine power off, and then unplug the machine power supply cord from the
power source.
When installing more than one SD card, perform the merge operation. (SD Card Appli Move)
1. Disconnect the network cable.
2. Loosen the screw and remove the SD card slot cover.
3. Insert the SD card into the upper slot.
4. Attach the SD card slot cover and fasten it.
To Next Page
