Special Tools and Lubricants
D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1 4-16 SM
Paper Feed Drive (Optional Bank)
Bank Drive Motor
Apply silent grease to the gear unit at the location shown below.
Location Pate name Note
[A] Bank drive
motor shaft
DC
MOTOR:GEAR:10W
Apply an 8mm wide band of grease, 5 to 13 mm
from the tip of the roller as shown.
Coating Amt. Maximum Minimum
[A]
