Ricoh SAVIN D0AP - Xps Direct Print Option Type P18 (M543-11); M34 (D3 En-18, -19, -20)2-107 2.22.1 Accessories; Installation Procedure

XPS Direct Print Option Type P18 (M543-11)/ M34 (D3EN-18, -19, -20)
SM 2-107 D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1
1BInstallation
2.22 XPS DIRECT PRINT OPTION TYPE P18 (M543-11)/
M34 (D3EN-18, -19, -20)
2.22.1 ACCESSORIES
No. Description Q'ty
1 XPS Direct Print SD card 1
2.22.2 INSTALLATION PROCEDURE
To prevent injury from electrical shock or damage to the machine, before installation always,
turn the main machine power off, and then unplug the machine power supply cord from the
power source.
When installing more than one SD card, perform the merge operation. (SD Card Appli Move)
1. Loosen the screw and remove the SD card slot cover.
Printer model:
MF model:
