Ricoh SAVIN D0AP - Printer Bit Switch Description; Some Possible Problems

Printing Features
D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1 6-4 SM
PDF
triggers
%PDF-
%!PS-Adobe-M.nPDF- (*M, n=numeric)
* "userdict" is excluded by configuring Printer Bit Switch 5-3=1.
• Up to 2KB from the start of the job can be searched for triggers.
• By configuring Printer Bit Switch 5-3=1:
• "%%" can be added to the PS triggers
• "userdict" is excluded
• If a job is identified as PDF, it will be sent to the PS interpreter to be processed as a
regular PS job.
PS interpreter
PCL5 trigger [ESC]E and 2 or more continuous PCL commands
• Up to 256 bytes from the start of each page can be searched for triggers.
Some possible problems
Garbled output:
If a string of characters (or binary data) is mistaken as a trigger and an incorrect PDL is applied,
the output will be garbled.
Incorrect printer settings:
Printer settings, for example the paper size, is incorrectly applied. This can happen when the
printer settings at the beginning of the job are initialized before a PDL switch occurred and no
settings were configured for the rest of the job.
Printer Bit Switch description
Bit Switch 2-3
This controls Auto PDL Detection by the PCL interpreter and PS interpreter.
BitSW 2-3=0 (default):
If PDL switching is applied to the job, all of the printer system, PCL interpreter and PS
interpreter will search for switching criteria (triggers).
BitSW 2-3=1:
Only the printer system will search for switching criteria (triggers). PCL/PS interpreters will not.
Bit Switch 5-3
This affects the PDL switching criteria (triggers) used by the printer system.
BitSW 5-3=0 (default):
"%%" is not used as a printer system PS trigger. "%%" will not call the PS interpreter.
