Data Overwrite Security Unit Type M19 (D3BS-03)
D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1 2-122 SM
2.27.3 ACCESSORIES
No. Description Q’ty
1 SD card 1
- Comments Sheet 1
- Operating Instructions CD-ROM 1
2.27.4 SEAL CHECK AND REMOVAL
Check the factory seals on the box and make sure the tamper proof seals are not broken and
the box unopened.
1. Check the seals [A] on each corner of the box.
• Make sure that a seal is attached to each corner.
• The surfaces of the seals must be blank. If you see “VOID” on the seals, do not install
the components in the box.
2. If the surfaces of the seals do not show “VOID”, remove them from the corners of the box.
3. You can see the “VOID” marks [B] when you remove each seal. In this condition, they
cannot be attached to the box again.
