Bit Switches – 5
SM 89 D0C5/D0C6/D0C4/D0AP FAX UNIT
(D0C5/D0C6
/D0C4/D0AP)
4.7 BIT SWITCHES – 5
• Do not adjust a bit switch or use a setting that is described as "Not used", as this may
cause the machine to malfunction or to operate in a manner that is not accepted by
local regulations. Such bits are for use only in other areas, such as Japan.
Default settings for bit switches are not listed in this manual. Refer to the System Parameter List
printed by the machine.
4.7.1 IP FAX SWITCHES
IP Fax Switch 00 (SP No. 1-111-001)
No. Function Comments
0 Not used Do not change this setting.
1 IP Fax Transport
0: T C P, 1: UDP
Selects TCP or UDP protocol for IP-Fax
2 IP Fax single port
selection
0: OF F, 1: ON
(enable)
Selects a single data port.
3 IP Fax double ports
(single data port)
selection
0: OF F, 1: ON
(enable)
Selects whether IP-Fax uses a double port.
4 IP Fax Gatekeeper
0: OF F, 1: ON
(enable)
Enables/disables the gatekeeper for IP-Fax.
5 IP Fax T30 bit signal
reverse
0: LSB first, 1: MSB
first
Reverses the T30 bit signal.
6 IP Fax max bitrate
setting
0: Not affected, 1:
Affected
When "0" is selected, the max bitrate does not affect the value of
the DIS/DCS.
When "1" is selected, the max bitrate affects the value of the
DIS/DCS.
7 IP Fax received
telephone number
confirmation
When "0" is selected, fax data is received without checking the
telephone number.
When "1" is selected, fax data is received only when confirming that
To Next Page
