Input and Output Check
SM 3-5 D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1
SP Mode
Tables
MFP/Printer
SP No. SP name Operation Restriction
5-804-009 DrumMt:CCW:Hi
5-804-010 DrumMt:CCW:Mif
5-804-011 DrumMt:CW:Low
5-804-012 DrumMt:CW:ExLow
5-804-013 FeedMt:CW:ExHi Rotates feed/fusing motor
forward.
Cannot switch on with
PCDU set.
5-804-014 FeedMt:CW:Hi
5-804-015 FeedMt:CW:Mid
5-804-016 FeedMt:CW:Low
5-804-017 FeedMt:CW:ExLow
5-804-018 FeedMt:CCW:ExHi Rotates feed/fusing motor in
reverse.
5-804-019 FeedMt:CCW:Hi
5-804-020 FeedMt:CCW:Mid
5-804-021 FeedMt:CCW:Low
5-804-022 FeedMt:CCW:ExLow
5-804-023 ExtRevMt:CW:ExHi Rotates exit/reverse motor
forward.
5-804-024 ExtRevMt:CW:Hi
5-804-025 ExtRevMt:CW:Mid
5-804-026 ExtRevMt:CW:Low
5-804-027 ExtRevMt:CW:ExLow
5-804-028 ExtRevMt:CCW:ExHi Rotates exit/reverse motor in
reverse.
5-804-029 ExtRevMt:CCW:Hi
5-804-030 ExtRevMt:CCW:Mid
5-804-031 ExtRevMt:CCW:Low
5-804-032 ExtRevMt:CCW:ExLow
5-804-033 PCDUFan:Left:High Operates PCDU cooling fan
(left)
5-804-034 PCDUFan:Left:Low
5-804-035 PSU Fan: High Operates PSU cooling fan.
5-804-036 PSU Fan: Low
5-804-037 HVP:Development Outputs each PWM. Cannot switch on with
PCDU set.
5-804-038 HVP:Charge
5-804-040 HVP:Transfer:+
5-804-041 HVP:Transfer:-
5-804-042 Drum QL Lights the quenching lamp.
5-804-044 Exit Junc SOL Turns exit junction gate
solenoid on.
5-804-045 PCDU Fan:Light Operates PCDU cooling fan
(right).
