Bit Switches – 4
D0C5/D0C6/D0C4/D0AP FAX UNIT 86 SM
0: Normal parameter
1: Specific parameter
detected when the "Normal parameter: 0" is selected.
7 Not used Do not change the settings.
G3 Switch 08 - Not used (do not change the settings)
G3 Switch 09 - Not used (do not change the settings)
G3 Switch 0A (SP No. 1-105-011)
No Function Comments
0-1 Maximum allowable
carrier drop during
image data reception
These bits set the acceptable modem carrier drop time.
Try a longer setting if error code 0-22 is frequent.
Bit 1 Bit 0 Value
(ms)
0 0 200
0 1 400
1 0 800
1 1 Not used
2 Select cancellation of
high-speed RX if carrier
signal lost while
receiving
0: Off
1: On
This switch setting determines if high-speed receiving ends if the
carrier signal is lost when receiving during non-ECM mode
3 Not used Do not change the settings
4 Maximum allowable
frame interval during
image data reception.
0: 5 s 1: 13 s
This bit set the maximum interval between EOL (end-of-line)
signals and the maximum interval between ECM frames from
the other end.
Try using a longer setting if error code 0-21 is frequent.
5 Not used Do not change the settings.
6 Reconstruction time for
the first line in receive
mode
0: 6 s 1: 12 s
When the sending terminal is controlled by a computer, there
may be a delay in receiving page data after the local machine
accepts set-up data and sends CFR. This is outside the T.3 0
recommendation. But, if this delay occurs, set this bit to 1 to give
the sending machine more time to send data.
Refer to error code 0-20.
ITU-T T.30 recommendation: The first line should come within 5
s of CFR.
7 Not used Do not change the settings.
To Next Page
