Safety Instructions for the Color Controller
Fuse
The color controller uses a double pole fuse. If this fuse blows, be sure to replace it with an
identical fuse.
Batteries
Always replace a battery with the same type of battery prescribed for use with the color
controller unit. Replacing a battery with any type other than the one prescribed for use could
cause an explosion.
• Never discard used batteries by mixing them with other batteries or other refuse.
• Always remove used batteries from the work site and dispose of them in accordance with
local laws and regulations regarding the disposal of such items.
SYMBOLS AND ABBREVIATIONS
This manual uses the following symbols and abbreviations:
Symbol What it means
Screw
Connector
Clip ring
Clamp
FFC (Flexible Flat Cable)
E-ring
Spring
SEF Short Edge Feed
LEF Long Edge Feed
[A] Short Edge Feed (SEF)
[B] Long Edge Feed (LEF)
