Scanner (MF Model Only)
D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1 4-70 SM
4. Disconnect the harnesses and FFCs from the scanner unit.
The FFC on the left side has a lock mechanism. Press the lock lever to disconnect it.
Set the ferrite core [A] in the holder when you connect the harnesses.
5. Remove the harness guide [A].
