Paper Feed
D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1 4-106 SM
2. Open the cover [A] of the bypass feed roller.
3. Remove the bypass feed roller [A] with the shaft.
Slide the shaft to the left, and then detach the right end of the roller first.
4. Release the hook to remove the bypass feed roller [A].
When attaching the bypass feed roller, insert the left end of the roller with the spring into
the hole [A] of side plate first. Then slide the roller to the left, and then insert the right end of
the roller into bearing [B].
