Maintenance Tables
SM 2-3 D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1
Maintenance
are categorized not as PM parts but as yield parts (EM parts). The parts with "(R)" in this table
are yield parts.
SPDF/Scanner (MF Model Only)
The PM count for the following items is based on the number of originals fed:
Item 30K 45K 120K EM Remarks
Exposure glass (for SPDF) C Wipe with a dry cloth
when cleaning.
Exposure glass (for platen mode) C Wipe with a dry cloth
when cleaning.
Original feed unit (pick-up roller and feed roller) (R) C Wipe with a damp
cloth when cleaning.
SPDF friction pad (R) C Wipe with a dry cloth
when cleaning.
Platen C C Wipe with a dry cloth
when cleaning.
Scanning guide plate (front side, rear side) C C Wipe with a dry cloth
when cleaning.
SPDF entrance roller, Pre-scanning roller (front
side, rear side), Exit roller, and each driven
roller
C Wipe with a damp
cloth when cleaning.
PCDU/LED Optics/Transfer/Fusing
Item 70K 180K EM Remarks
PCDU R
LED head C When vertical lines or bands occurs,
User: Opening and closing the front door four times.
CE: Pushing the links of the LED unit four times.
Transfer roller (R) Replace referring to logging counter.
Fusing unit (R) Replace referring to logging counter.
Paper Feed/ Exit
Item 70K 180K EM Remarks
Paper feed roller (Tray 1) C
• Clean with alcohol.
• Replace when a feeding failure occurs.
Separation roller (Tray 1) C
• Clean with alcohol.
• Replace when a double feed occurs.
Bypass feed roller C
• Clean with alcohol.
• Replace when a feeding failure occurs.
Bypass friction pad C
• Clean with alcohol.
To Next Page
