SP7-XXX (Data Log) - Controller
SM 5-71 D0AP/D0C4/D0C5/D0C6/M0BQ/M0D1
Tables
SP No. Large Category Small Category ENG
or
CTL
[Min to Max / Init. /
Step]
7-504-009 Paper Jam Location Duplex: No Feed CTL* [0 to 65535 / 0 / 0]
7-504-013 Paper Jam Location Tray2 Vertical Trans Sensor
Late Jam
CTL* [0 to 65535 / 0 / 0]
7-504-014 Paper Jam Location Tray3 Vertical Trans Sensor
Late Jam
CTL* [0 to 65535 / 0 / 0]
7-504-017 Paper Jam Location Registration Sensor Late
Jam
CTL* [0 to 65535 / 0 / 0]
7-504-020 Paper Jam Location Inverter Exit Sensor Late
Jam
CTL* [0 to 65535 / 0 / 0]
7-504-026 Paper Jam Location Duplex Entrance Sensor
Late Jam
CTL* [0 to 65535 / 0 / 0]
7-504-033 Paper Jam Location Tray1:No Feed Continuous CTL* [0 to 65535 / 0 / 0]
7-504-034 Paper Jam Location Tray2: No Feed Continuous CTL* [0 to 65535 / 0 / 0]
7-504-035 Paper Jam Location Tray3:No Feed Continuous CTL* [0 to 65535 / 0 / 0]
7-504-036 Paper Jam Location Tray4:No Feed Continuous CTL* [0 to 65535 / 0 / 0]
7-504-038 Paper Jam Location Duplex:No Feed
Continuous
CTL* [0 to 65535 / 0 / 0]
7-504-053 Paper Jam Location Tray2 Vertical Trans Sensor
Lag Jam
CTL* [0 to 65535 / 0 / 0]
7-504-054 Paper Jam Location Tray3 Vertical Trans Sensor
Lag Jam
CTL* [0 to 65535 / 0 / 0]
7-504-055 Paper Jam Location Tray4 Vertical Trans Sensor
Lag Jam
CTL* [0 to 65535 / 0 / 0]
7-504-057 Paper Jam Location Registration Sensor Lag
Jam
CTL* [0 to 65535 / 0 / 0]
7-504-060 Paper Jam Location Inverter Exit Sensor Lag
Jam
CTL* [0 to 65535 / 0 / 0]
7-504-066 Paper Jam Location Duplex Entrance Sensor
Lag Jam
CTL* [0 to 65535 / 0 / 0]
7-505-001 Original Jam Detection Initial Jam CTL* [0 to 65535 / 0 / 0]
7-505-004 Original Jam Detection Registration Sensor Late
Jam
CTL* [0 to 65535 / 0 / 0]
7-505-013 Original Jam Detection Sensor Late Jam After Feed CTL* [0 to 65535 / 0 / 0]
7-505-054 Original Jam Detection Registration Sensor Lag
Jam
CTL* [0 to 65535 / 0 / 0]
7-505-063 Original Jam Detection Sensor Lag Jam After Feed CTL* [0 to 65535 / 0 / 0]
