Bit Switches – 2
SM 71 D0C5/D0C6/D0C4/D0AP FAX UNIT
(D0C5/D0C6
/D0C4/D0AP)
Printer Switch 09 - Not used (do not change the settings)
Printer Switch 0A - Not used (do not change the settings)
Printer Switch 0B - Not used (do not change the settings)
Printer Switch 0C - Not used (do not change the settings)
Printer Switch 0E (SP No. 1-103-015)
No Function Comments
0* Paper size selection priority
0: Width
1: Length
0: A paper size that has the same width as the received
data is selected first.
1: A paper size which has enough length to print all the
received lines without reduction is selected first.
1* Paper size selected for
printing A4 width fax data
0: 8.5" x 11" size
1: A4 size
This switch determines which paper size is selected for
printing A4 width fax data, when the machine has both A4
and 8.5" x 11" size paper.
2 Page separation
0: Enabled
1: Disabled
1: If all paper sizes in the machine require page separation
to print a received fax message, the machine does not print
the message (Substitute Reception is used).
After a larger size of paper is set in a cassette, the machine
automatically prints the fax message.
3-4 Printing the sample image on
reports
"Same size" means the sample image is printed at 100%,
even if page separation occurs.
User Parameter Switch 19 (13H) bit 4 must be set to "0" to
enable this switch.
Refer to Detailed Section Descriptions for more on this
feature.
Bit
4
Bit
3
Setting
0 0 The upper half
only
0 1 50% reduction
(sub-scan only)
1 0 Same size
1 1 Not used
5-6 Not used Do not change the settings.
7 Equalizing the reduction ratio
among separated pages
(Page Separation)
0: Enabled
1: Disabled
0: When page separation has taken place, all the pages are
reduced with the same reduction ratio.
1: Only the last page is reduced to fit the selected paper
size when page separation has taken place. Other pages
are printed without reduction.
* This setting can be used for the client-side machine which has no FCU.
Printer Switch 0F (SP No. 1-103-016)
No Function Comments
