Stober SD6 - Page 309

ID 442426.04 309WE KEEP THINGS MOVING
Optimize
15
Manual SD6
D-part of the torque controller.
Magnetizing current in amps.
Torque generating current in amps.
Voltage in d direction in V (linked peak voltage).
Voltage in q direction in V (linked peak voltage).
Reference value of the magnetization current.
Reference value for the torque generating current as a A.
B68 kd-iq version 0
E92 I-d version 0
E93 I-q version 0
E98 Ud version 1
E99 Uq version 1
E165 Id-ref version 0
E166 Iq-ref version 0
