ID 442426.04 311WE KEEP THINGS MOVING
Optimize
15
Manual SD6
Action time of the current controller for the flow generating part in ms. A setting
below 0.3 ms will result in an integral gain of 0 (equivalent to an infinite action
time).
Proportional gain of the flow controller.
D-part of the torque controller.
Shows the current motor current as an amount in amps.
Magnetizing current in amps.
Torque generating current in amps.
Voltage in d direction in V (linked peak voltage).
Voltage in q direction in V (linked peak voltage).
Reference value of the magnetization current.
Reference value for the torque generating current as a A.
B66 integral time Id version 0
B67 proportional gain flux version 0
B68 kd-iq version 0
E00 I-Motor version 0
E92 I-d version 0
E93 I-q version 0
E98 Ud version 1
E99 Uq version 1
E165 Id-ref version 0
E166 Iq-ref version 0
