ID 442426.04 396WE KEEP THINGS MOVING
Diagnosis
16
Manual SD6
16.25 55:Option module
Triggering Level Response Counter
Error when operating with option module. Fault Parameterized fault response in A29:
• A29 = 0:inactive
The power board is switched off and the drive
becomes torque-free/force-free. If the air override is
inactive, a possibly existing brake will be controlled to
close.
• A29 = 1:active
The drive is stopped with a quick stop. If the air
override is inactive, a possibly existing brake will be
controlled to close at the end of the quick stop.
Z55
Cause Description Measure Confirmable
1:incorrectOption1 Incorrect or missing communication module
(compare E54/E58 with E68/E69)
• Install the projected communication
module.
• Adjust the projection.
Yes
2:EC6failure EC6 was detected, installed and failed. • Uninstall and reinstall ED6.
• Replace EC6.
Yes
3:CA6failure CA6 was detected, installed and failed. • Uninstall and reinstall CA6.
• Replace CA6.
Yes
7:incorrectOption2 Incorrect or missing terminal module
(compare E54/E58 with E68/E69)
• Install the projected terminal module.
• Adjust the projection.
Yes
10:XI6failure X16 was detected, installed and failed. • Uninstall and reinstall X16.
• Adjust the projection.
Yes
12:24Vfailure A failure of the 24 vdc power supply of XI6
was detected.
Check and, if necessary, correct the 24 vdc
power supply of X16.
Yes
