Diagnosis
16
Manual SD6
16.30 60-67:Application events 0-7
Triggering Level Response Counter
Application-specific or based on free programming
option; can be separately programmed for each
axis:
• Message/warning: Evaluation occurs in 256
ms cycle.
• Fault: Evaluation occurs in parameterized
cycle time (A150).
Parameterized
level in U100,
U110, etc to
U170:
•Inactive
• Message
• Warning
•Fault
Parameterized fault response in A29:
• A29 = 0:inactive
The power board is switched off and the drive
becomes torque-free/force-free. If the air override is
inactive, a possibly existing brake will be controlled to
close.
• A29 = 1:active
The drive is stopped with a quick stop. If the air
override is inactive, a possibly existing brake will be
controlled to close at the end of the quick stop.
Z60 to Z67
Possible cause Test Measure Confirmable
Application-specific or based on free
programming option; can be
separately programmed for each
axis.
——Yes
