ID 442426.04 402WE KEEP THINGS MOVING
Diagnosis
16
Manual SD6
16.31 68: External fault
Triggering Level Response Counter
Application-specific or by free programming
option; should be used for application events that
may only be parameterized on the fault level.
Fault Parameterized fault response in A29:
• A29 = 0:inactive
The power board is switched off and the drive
becomes torque-free/force-free. If the air override is
inactive, a possibly existing brake will be controlled to
close.
• A29 = 1:active
The drive is stopped with a quick stop. If the air
override is inactive, a possibly existing brake will be
controlled to close at the end of the quick stop.
Z68
Possible cause Test Measure Confirmable
Application-specific or by free
programming option
——Yes
