ID 442426.04 403WE KEEP THINGS MOVING
Diagnosis
16
Manual SD6
16.32 69:Motor connect.
Triggering Level Response Counter
Motor connection error Parameterized
level in U12:
•Inactive
•Fault
Parameterized fault response in A29:
• A29 = 0:inactive
The power board is switched off and the drive
becomes torque-free/force-free. If the air override is
inactive, a possibly existing brake will be controlled to
close.
• A29 = 1:active
The drive is stopped with a quick stop. If the air
override is inactive, a possibly existing brake will be
controlled to close at the end of the quick stop.
Z69
Cause Description Measure Confirmable
1:motorNotDiscon The contactor did not open during the axis
change. This cause can only be determined
when at least two phases stick and the
intermediate circuit E03 is loaded.
Replace the contactor. Yes
2:no motor Possibly no motor connected or the line to
the motor is interrupted.
Check the connection of the motor.
