ID 442426.04 422WE KEEP THINGS MOVING
Diagnosis
16
Manual SD6
16.44 81:motor allocation
Triggering Level Response Counter
The event is triggered if any motor other than the
projected one is detected when the electronic
nameplate is mapped.
Fault The power board remains switched off and the drive is
torque-free/force-free. IIf the air override is inactive, a
possibly existing brake will be controlled to close.
Depending on the cause, the required parameter values
are read from the electronic nameplate.
Z81
Cause Description Measure Confirmable
1:Modified motor type The connected motor type does not match
the saved motor type (for example EZ402
instead of EZ401).
Perform A00 save values.Yes
32:Modified motor The connected motor does not match the
saved motor, for example it has a different
serial number.
Perform A00 save values.Yes
33: different motor & brake The connected motor and its brake do not
match the saved motor and the saved
brake.
Perform A00 save values.Yes
34: different motor & temperature
sensor
The connected motor and its temperature
sensor do not match the saved motor and
the temperature sensor.
Perform A00 save values.Yes
35: different motor & brake &
temperature sensor
The connected motor, its brake and its
temperature sensor do not match the saved
motor brake and the temperature sensor.
Perform A00 save values.Yes
64: different commutation The commutation of the connected motor
does not match the saved commutation.
Perform A00 save values.Yes
65:Modified commutation and brake The commutation of the connected motor
and the brake do not match the saved
commutation and the saved brake.
Perform A00 save values.Yes
