Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-18
Scanner
Maintenance
White Balance Adjusts the white balance automatically. 2-61
Shading Parameter Specifies the Shading factor setting. 2-61
Registration Param. Adjusts the Registration. 2-62
Auto Registration Specifies whether the Auto Reg adjust function to set
to ON or OFF.
2-62
Sensor Parameter Specifies the power control value of the Feed Sensor. 2-62
Vertical Scan Mag. Specifies the parameter setting of the magnification
for the vertical scanning.
2-62
Test Pattern Specifies the test pattern and the parameter setting. 2-63
IIT I/O Check Checks the input and output of the scanner
components.
2-63
Scan Counter Clear Clear the scan counter. 2-64
Carriage Drive_100 2-64
Parameter Specifies the system data setting using ChainLink.
Backup
Data
All Clear Deletes the SRAM/EEPROM backup data.
User Clear Deletes the SRAM/EEPROM backup data.
System Clear Deletes the SRAM/EEPROM backup data.
User&System Clear Deletes the SRAM/EEPROM backup data.
System Data Init Deletes the SRAM/EEPROM backup data.
Document Clear Deletes the document data in the Fax Flash Memory.
Complete Complete Exits Service Mode and restarts the printer.
Fax/Scanner Diag Function Names and Details
Function Description See

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
