Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-112
WorkCentre 6605 Error Code List
071
072
075
921
921
921
Waiting for
dashdashSetdas
hdash key to be
pressed after
setting side 2 for
manual duplex
print(Tray)
Tray
Tray 1 : 071
Tray 2 : 072
Manual Feed : 075
Press Ok Button
to continue
-
WorkCentre 6605 Error Code List
Chain Link Error Error Details Control Panel Messages
FIP
location
004 310 IOT Feeder I/F
Failure
IOT-FEEDER
communication error
Optional Feeder Error 004-310
Reseat Optional Feeder.
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Page 2-178
005 110 PICKUP JAM Detect PICKUPJAM Paper Jam
Open the Document Feeder Cover
and remove paper.
<After Jam recovery>
Reload the original that was
removed from the Document
Feeder and press the Start button.
N Scanned
Page 2-208
005 121 ADF JAM Detect ADFJAM Paper Jam
Open the Document Feeder Cover
and remove paper.
<After Jam recovery>
Reload the original that was
removed from the Document
Feeder and press the Start button.
N Scanned
Page 2-208
005 124 Virtual JAM Detect HARFJAM Document Feeder Jam
Job Canceled.
Open Document Feeder Cover
and Remove Jammed Paper.
Page 2-208
005 301 ADF Cover Open ADF cover open Document Feeder Cover Open
Close Document Feeder Cover.
Page 2-209
Phaser 6600 Error Code List
Chain Link Error Error Details Control Panel Messages FIP location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
