Xerox WorkCentre 6605 Service Manual

Wiring
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
7-24
Connection Details
This table lists the thirteen wiring diagrams and the details of the connections shown in each diagram.
Except for the Controllers, diagrams 1-12 are the same for the MFP and SFP; diagram 13 covers the
Scanner and applies only to the MFP.
Diagram Connection Details
1 AC Power Connections of LVPS with MCU Board.
Connections of AC IN Assembly with LVPS.
Connections of Main Fan with LVPS.
Connections of Rear Interlock Switch with LVPS.
Connections of Door Interlock Switch with LVPS.
Connections of MCU Board with Toner Full Sensor.
2 Fuser Connections of FUSING Assembly with LVPS.
Connections of FUSING Assembly with MCU Board.
Connections of LVPS with MCU Board.
3 Drive Connections of DRIVE Assembly with MCU Board.
Connections of DRIVE Assembly with LVPS.
4 Bypass Tray
(MSI)
Connections of Bypass Tray Sensor with MCU Board.
Connections of Bypass Tray No Paper Sensor with MCU Board.
Connections of DRIVE Assembly with MCU Board.
Connections of Bypass Tray Feed Solenoid with MCU Board.
5 Laser Unit Connections of Laser Unit with MCU Board.
Connections of Laser Unit with PWBA LVPS.
6 SFP Controller Connections of IP Board with MCU Board.
Connections of IP Board with LVPS.
Connections of IP Board with Laser Unit.
Connections of IP Board with Control Panel.
Connections of IP Board with USB Bracket Assembly.
6 MFP Controller Connections of IP Board with MCU Board.
Connections of IP Board with LVPS.
Connections of IP Board with Laser Unit.
Connections of IP Board with FAX Board.
Connections of IP Board with USB Hub Board.
Connections of USB Hub Board with Control Panel Assembly .
7 Paper Transport Connections of Regi Clutch with MCU Board.
Connections of Regi Chute Assembly with MCU Board.
Connections of Feed Clutch with MCU Board.
Connections of Duplex Clutch with MCU Board.
8 HVPS Connections of HVPS XERO DEVE with HVPS TR.
Connections of HVPS XERO DEVE with MCU Board.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
