Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-89
Error Messages
Error messages generated by the printer’s operating system are the lead-in to the troubleshooting
procedures that follow in subsequent pages. This section correlates the output of the printer’s
diagnostic aids and provides the troubleshooting procedures to locate and correct the reported errors.
Error Message Abbreviations
Due to limited display space, some error messages include abbreviations. The most common
abbreviations used throughout this chapter are listed here.
Term Definition
ADC Automatic Density Control
ASIC Application-Specific Integrated Circuit
COMM Communication
CRT Cartridge
CRUM Customer Replaceable Unit Monitor
ER/ERR Error
ENV Environment
FUNC Function
IBT Transfer Belt
KBlack
MACaddress Media Access Control Address
MCU Machine Control Unit
NVM Non-Volatile Memory. Used instead of NVRAM.
NVRAM Non-Volatile Random Access Memory
PDL Page Description Language
RAM Random Access Memory
REGI Registration
ROM Read Only Memory

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
