6. Press the OK button.
The number changed will be written in and the screen returns to the previous screen.
7. Press the Back button to return to the [Printer Diag] screen.
8. Exit Service Mode. See “How to Exit Service Mode” on page 2-10.
Print Function Test (Test Print)
You can perform the Test Print using the prepared patterns for the print test. In the event of paper jam
or out of paper, wait until the error is released.
Note: Do not remove the cassette while the test is being executed. Before the print test, check that
the paper tray contains enough paper.
Procedure for the Print Function Test
This section explains how to print a test pattern using Pattern IOT as an example.
1. Enter Service Mode. See “How To Enter Service Mode” on page 2-8.
2. Confirm that [Printer Diag] is selected, and press the OK button.
3. Use the [ ] button to select [Test Print], and press the OK button.
4. Use the [ ] button to select [Pattern IOT], and press the OK button.
5. Press the OK button to print the test pattern.
The screen will return to the [Ready] screen after printing.
6. Press the Back button to return to the [Printer Diag] screen.
7. Exit Service Mode. See “How to Exit Service Mode” on page 2-10.
Installation
SerialNo.
Printer Diag
Installation
Printer Diag
Test Print
Test Pri nt
No Image IOT
Test Pri n t
Pattern IOT
Pattern IOT
Ready
Pattern IOT
Processing
Pattern IOT
Ready
Printer Diag
Test Print

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
