Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-65
System Data Setting (Parameter)
You can specify the Fax and Scan system data settings.
Procedure
1. Enter Service Mode. See “How To Enter Service Mode” on page 2-8.
2. Use the [ ] button to select [Fax/Scanner Diag], and press the OK button.
3. Use the [ ] button to select [Parameter], and press the OK button.
4. Change the Chain Link number, and press the OK button.
Use the [ ] and [ ] buttons to move the cursor to right and left.
Use the [ ] and [ ] buttons to increase or decrease the value where the cursor is placed.
Press the OK button, and the Chain Link number changed will appear.
5. Change the setting value, and press the OK button.
* (asterisk) will appear when the value is set.
6. Press the Back button to return the [Fax Scanner Diag] screen.
7. Exit Service Mode. See “How to Exit Service Mode” on page 2-10.
Fax/Scanner Diag
Parameter
Parameter
Chain Link: 101-001
Value(Hex): B5
Cursor
Cursor
Parameter
Chain Link: 101-007
Value(Hex): B
Parameter
Chain Link: 101-007
Value(Hex): *43
Fax/Scanner Diag
Parameter

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
