Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-23
8. Press the OK button to obtain data from the device specified.
9. [CHECK OK] will appear when the data is obtained normally.
When the data is not obtained normally, [CHECK NG] will appear, and when the request was not
transferred to the device, [Send Error] will appear.
10. Press the Back button to return to the [Printer Diag] screen.
11. Exit Service Mode. See “How to Exit Service Mode” on page 2-10.
Get Device Info
Get Device Info displays the VID, PID, Add, and Prt information of the device connected. [Read Error]
will appear when the device information is not obtained.
• VID: [Vendor ID] value of a device collected by the Device Descriptor
• PID: [Product ID] value of a device collected by the Device Descriptor
• Add: [Device Address] assigned to the device
• Prt: The port number of a connected controller or the downstream port number of the hub
RTC Test
RTC Test checks the time by backing up the current time and writing the default values, and then
checking, after a certain period of time, whether the time reaches the expected time.
* Performing RTC Test will delay the internal clock of the printer by 2 seconds.
Engine Diag
Sensor Test
Digital Input checks whether the digital input (DI) components function properly.
The display shows [0] when the digital input test is started, and the value will be increased when the DI
components are switched from OFF to ON, which is used for confirming that the component functions
normally. The test targets all DI components.
Normal Error
CHECK OK RTC ERROR
Single Step
CHECK OK
Printer Diag
ESS Diag

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
