Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-22
Test M o d e
Test Mode (when the optional USB Host is installed)
Note: To complete the test mode, restart the printer.
Single Step
Single Step allows you to collect Device Descriptor from the device you specify.
Procedure
1. Enter Service Mode. See “How To Enter Service Mode” on page 2-8.
2. Confirm that the [Printer Diag] is selected, and then press the OK button.
3. Press the OK button.
4. Use the [ ] button to select [USB Host Test], and press the OK button.
5. Use the [ ] button to select [Single Step], and press the OK button.
6. Specify the device address. (Available addresses are 0 to 127.)
Use the [ ] and [ ] buttons to move the cursor to right and left.
Use the [ ] and [ ] buttons to increase or decrease the value where the cursor is placed.
7. Press the OK button to transfer a request to the device specified.
Item Description
TEST MODE TEST J Keeps J state for the DownStream port of the Host Controller.
TEST K Keeps K state for the DownStream port of the Host Controller.
TEST SE0 Keeps SE0 state for the DownStream port of the Host Controller.
TEST PACKET Repeatedly sends the test packet form the DownStream port of the
Host Controller.
Printer Diag
ESS Diag
ESS Diag
All Test
ESS Diag
USB Host Test
USB Host Test
TEST MODE
USB Host Test
Single Step
Single Step
Address: 000
Cursor
Single Step
Single Step
DATA IN
Single Step
Address: 002

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
