Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-21
ASIC Test
ASIC Test reads the device ID of the REMORA-EX via ZoranQuatro4530 and performs the Zoran
Quatro4530 and REMORA-EX tests.
Engine Test
IOT Test provides the communication test between the IOT. In this communication test, the IOT
status register is read for checking whether the commands are exchanged normally.
Hard Drive Test
Use the Device Diagnostic Command to perform the Hard Disk Test.
USB Host Test
USB Host Test checks the communication between a USB Host port and the USB devices connected to
the USB Host port.
* This test menu is for obtaining the USB authentication. To use this test, you will need the devices
approved by the certification authority.
Normal Error
CHECK OK ASIC CHECK NG
Normal Error
CHECK OK IOT ERROR
Normal Error
CHECK OK Hard Disk ERROR

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
