Xerox WorkCentre 6605 Service Manual

Wiring
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
7-30
AC Power
MCU Board
PL18.1.13
AC Inlet
PL18.1.31
LINE
Neut
Main
Switch
LVPS
PL18.1.34
P/J48
1
2
3
P/J503
1
2
3
4
Main Fan
PL4.1.13
ON
RTN
ALRM
1
2
P/J42
3
1
2
3
P/J41
4
Rear Interlock
Switch
PL14.1.3
Door Interlock
Switch
PL19.1.30
P/J43
2
1
SG
LD 5V
ON/OFF
STBY
+5VDC
10
9
8
P/J501
7
FAN
Drive
6
5
4
P/J501
12
11
3
1
P/J40
6
5
216
2
P/J30
1
17
I/L +24VDC
I/L +24VDC
RTN
2
3
4
P/J509
1
RTN
RTN
To Drive
To ROS
To IP Board
To Fuser
N.C.
P/J29
6
9
8
7
12
P/J29
11
10
15
14
13
REAR IL
DOOR IL
FAN LOW
FAN STOP
FAN ALRM
+3.3VDC
POWER ON
SG
SG
+5VDC
I/L
+24VDC
+3.3VDC
+5VDC
A
From IP Board
+3.3VDC
+24VDC
B
I/L +24VDC
I/L +24VDC
I/L +24VDC
4
3
2
1
+5VDC
SG
P/J29
18
19
+5VDC
SG
20
WASTE BOX FULL SENSED SIGNAL
P/J203
3
2
1
Toner Full Sensor
PL4.1.17
+5VDC
Top Harness Assembly
PL18.2.5
P/J507
1
2
P/J5071
1
2
Top Harness Assembly
PL18.2.5
To ROS
+24VDC
RTN
s6600-213
+5VDC

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
