Xerox WorkCentre 6605

Parts Lists
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
5-21
Parts List 7.1 Fuser
Parts List 7.1 Fuser
Item Name Part Number
1A Fusing Assy 110V (Fuser Assembly) 676K20790
1B Fusing Assy 220V (Fuser Assembly) 676K20800
2— —
3— —
4— —
5A Harness Assy Htr 100V (Heater Harness Assembly) —
5B Harness Assy Htr 200V (Heater Harness Assembly) —
s6600-039
Front
1
5
(J47)
(P281)
