Xerox WorkCentre 6605 Service Manual

Service Parts Disassembly
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
4-115
Covers
SFP Top Cover Assembly
PL19.1.1
WARNING: The Fuser is very hot. Take added care when handling the fuser to avoid being burned.
1. Remove the Right Cover Assembly. (page 4-131)
2. Remove the Left Cover Assembly. (page 4-134)
3. Remove the Left Sub-top Cover. (page 4-126)
4. Remove the Exit Cover. (page 4-125)
5. Open the Top Cover Assembly.
6. Remove the Transfer 2 Link (PL19.1.4) from the Transfer Link Coupling.
7. Remove the two screws (silver, tapping, 8mm) that attach the Right Hinge Bracket (PL19.1.20) to
the printer and remove the bracket.
8. Shift the Top Cover Assembly to the right to release the cover from the Left Hinge Bracket
(PL19.1.15), then lift up to remove the cover from the printer.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
